| 브랜드 이름: | DLX |
| 모델 번호: | Cr30Ni70 |
| 모크: | 10kg |
| 지불 조건: | L/C,D/A,D/P,T/T,웨스턴 유니온,MoneyGram |
| 공급 능력: | 한 달에 500 톤 |
| Performance / Material | Cr10Ni90 | Cr20Ni80 | Cr30Ni70 | Cr15Ni60 | Cr20Ni35 | Cr20Ni30 |
|---|---|---|---|---|---|---|
| Ni Composition | 90 | Rest | Rest | 55.0~61.0 | 34.0~37.0 | 30.0~34.0 |
| Cr Composition | 10 | 20.0~23.0 | 28.0~31.0 | 15.0~18.0 | 18.0~21.0 | 18.0~21.0 |
| Fe Composition | -- | ≤1.0 | ≤1.0 | Rest | Rest | Rest |
| Maximum Temperature (°C) | 1300 | 1200 | 1250 | 1150 | 1100 | 1100 |
| Melting Point (°C) | 1400 | 1400 | 1380 | 1390 | 1390 | 1390 |
| Density (g/cm³) | 8.7 | 8.4 | 8.1 | 8.2 | 7.9 | 7.9 |
| Resistivity at 20°C (μΩ·m) | -- | 1.09±0.05 | 1.18±0.05 | 1.12±0.05 | 1.00±0.05 | 1.04±0.05 |
| Elongation at Rupture | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 |
| Specific Heat (J/g·°C) | -- | 0.44 | 0.461 | 0.494 | 0.5 | 0.5 |
| Thermal Conductivity (KJ/m·h°C) | -- | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 |
| Coefficient of Linear Expansion a×10⁻⁶/(20~1000°C) | -- | 18 | 17 | 17 | 19 | 19 |
| Micrographic Structure | -- | Austenite | Austenite | Austenite | Austenite | Austenite |
| Magnetic Properties | -- | Non-magnetic | Non-magnetic | Non-magnetic | Weak magnetic | Weak magnetic |
| Shape | Size (mm) |
|---|---|
| Wire | 0.05-7.5 |
| Rod | 8-50 |
| Ribbon | (0.05-0.35)×(0.5-6.0) |
| Strip | (0.5-2.5)×(5-40) |
