0Cr21Al6Nb FeCrAl Wire for High-Efficiency Electrolysis Hydrogen Systems

브랜드 이름:	DLX
모델 번호:	FeCrAl 합금 와이어 0Cr21Al6Nb
모크:	10kg
지불 조건:	L/C,D/A,D/P,T/T,웨스턴 유니온
공급 능력:	달 당 500 톤

자세한 정보

제품 설명

자세한 정보

원래 장소:

중국,장쑤성

인증:

Ce,Rohs

공급 능력:

달 당 500 톤

강조하다:

FeCrAl resistance wire for electrolysis

0Cr21Al6Nb high-efficiency wire

hydrogen system resistance wire

제품 설명

0Cr21Al6Nb FeCrAl Wire for High-Efficiency Electrolysis Hydrogen Systems

As the world moves toward a cleaner and more sustainable energy future, hydrogen production through water electrolysis has become a cornerstone of green energy strategies. Electrolysis, especially when powered by renewable sources such as solar and wind, offers a reliable and environmentally friendly way to produce hydrogen. The efficiency and reliability of electrolysis systems depend heavily on the materials used, particularly the resistance wire. The 0Cr21Al6Nb FeCrAl Wire is designed to meet the demanding conditions of electrolysis systems, offering superior performance, longevity, and stability in high-efficiency hydrogen production applications.

Product Overview

The 0Cr21Al6Nb FeCrAl Wire is a high-performance alloy wire composed of iron (Fe), chromium (Cr), aluminum (Al), and niobium (Nb). This unique blend of metals provides outstanding resistance to oxidation, corrosion, and mechanical wear, making it the ideal choice for electrolyzers used in hydrogen production. The wire is engineered to endure high temperatures, aggressive electrolytic environments, and prolonged operation, ensuring that electrolysis systems run efficiently for extended periods without compromising performance.

With the increasing demand for green hydrogen, the 0Cr21Al6Nb FeCrAl Wire helps maintain the durability and efficiency of electrolysis systems, making it an indispensable material for high-efficiency hydrogen production.

Parameter Comparison Table

Alloy Nomenclature Performance	1Cr13Al4	0Cr25Al5	0Cr21Al6	0Cr23Al5	0Cr21Al4	0Cr21Al6Nb	0Cr27Al7Mo2
Chemical Composition (%) - Cr	12.0-15.0	23.0-26.0	19.0-22.0	20.5-23.5	18.0-21.0	21.0-23.0	26.5-27.8
Chemical Composition (%) - Al	4.0-6.0	4.5-6.5	5.0-7.0	4.2-5.3	3.0-4.2	5.0-7.0	6.0-7.0
Chemical Composition (%) - Re	Opportune	Opportune	Opportune	Opportune	Opportune	Opportune	Opportune
Chemical Composition (%) - Fe	Rest	Rest	Rest	Rest	Rest	Rest	Rest
Max. Continuous Service Temp. of Element (°C)	950	1250	1250	1250	1100	1350	1400
Resistivity at 20°C (μΩ.m)	1.25	1.42	1.42	1.35	1.23	1.45	1.53
Density (g/cm³)	7.4	7.1	7.16	7.25	7.35	7.1	7.1
Tensile Strength (N/mm²)	580-680	630-780	630-780	630-780	600-700	650-800	680-830
Elongation at Rupture (%)	>16	>12	>12	>12	>12	>12	>10

Available Shapes and Sizes

Shape	Size (mm)
Wire	0.05-7.5
Rod	8-50
Ribbon	(0.05-0.35)*(0.5-6.0)
Strip	(0.5-2.5)*(5-180)

Key Features & Advantages

Excellent Oxidation Resistance
The 0Cr21Al6Nb FeCrAl Wire is specifically designed to resist oxidation at high temperatures (up to 1000°C), ensuring long-term stability and preventing premature degradation. This feature is crucial in maintaining the wire's performance and longevity in electrolyzers, where the material is exposed to high oxidative stress.
Outstanding Corrosion Resistance
Electrolysis environments are often harsh, with high levels of electrolytic fluids that can quickly corrode less durable materials. The 0Cr21Al6Nb FeCrAl Wire excels in resisting corrosion, allowing the electrolysis system to function efficiently over time without the need for frequent replacements or repairs.
High Temperature Stability
With an operating temperature range of up to 1000°C, this wire can handle the high-temperature conditions typical in advanced hydrogen electrolysis systems. Its ability to withstand these extreme temperatures ensures that the electrolysis process remains stable and efficient.
Superior Mechanical Strength
The wire offers excellent mechanical properties, with a tensile strength range of 450-800 MPa. Its high melting point (1550°C) adds to its ability to perform under mechanical stress and at high temperatures, ensuring that it can withstand the demanding conditions of continuous electrolysis.
Customizable for Diverse Applications
Whether you're working with small-scale laboratory setups or large industrial hydrogen production systems, the 0Cr21Al6Nb FeCrAl Wire can be customized to meet your specific requirements. DLX offers a range of wire diameters, strengths, and other specifications to ensure compatibility with your system.
Cost-Effective for Long-Term Use
Thanks to its durability and low maintenance needs, the 0Cr21Al6Nb FeCrAl Wire reduces operational costs. The reduced frequency of replacements, coupled with its long lifespan, makes it a cost-effective solution for large-scale hydrogen production systems.

Industry Trends & Market Insights

The global hydrogen economy is expanding rapidly, driven by the need for cleaner energy sources and the rise of renewable energy technologies. Electrolysis, particularly water electrolysis powered by renewable energy, has become one of the most promising methods for producing green hydrogen. The market for electrolysis systems is growing as hydrogen is increasingly seen as a key solution for decarbonizing sectors such as transportation, industry, and energy storage.

To meet the increasing demand for hydrogen and optimize production efficiency, the materials used in electrolysis systems need to be both durable and efficient. The 0Cr21Al6Nb FeCrAl Wire is perfectly suited for these applications, offering superior resistance to high temperatures, oxidation, and corrosion—making it ideal for use in advanced electrolysis systems.

Applications

Hydrogen Fuel Cells: The wire is an essential component of hydrogen fuel cells, which are used in applications such as fuel-cell vehicles, stationary energy systems, and backup power generation. The wire's longevity and efficiency ensure that hydrogen fuel cells continue to operate at peak performance.
Green Hydrogen Production: Electrolyzers powered by renewable energy use the 0Cr21Al6Nb FeCrAl Wire to produce green hydrogen efficiently. This hydrogen is key to decarbonizing sectors such as industrial production, transportation, and energy storage.
Energy Storage: Hydrogen produced via electrolysis can be stored and used later as a clean energy source. The 0Cr21Al6Nb FeCrAl Wire ensures that the electrolysis process remains efficient, allowing excess renewable energy to be converted into hydrogen and stored for future use.
Industrial Hydrogen Applications: The wire is also used in industrial applications such as hydrogen production for steel manufacturing, ammonia synthesis, and refining processes, where hydrogen is a vital feedstock and fuel.

Why DLX?

DLX stands out as a leading supplier of high-quality materials for the hydrogen production sector. Our 0Cr21Al6Nb FeCrAl Wire is designed for high-efficiency electrolysis systems, offering superior performance and durability. Here's why DLX is the right choice for your hydrogen production needs:

Uncompromising Quality: DLX ensures that every wire meets the highest standards of quality and performance, so you can rely on the material for consistent, long-term performance.
Customization for Your Needs: We understand that every electrolysis system is unique. That's why we offer a wide range of customization options, from wire diameter to tensile strength, to ensure that our wire meets your specific requirements.
Expert Consultation and Support: Our team of experts is always ready to assist you in selecting the right material for your electrolysis system. We provide technical support and recommendations to help you optimize your hydrogen production process.
Global Reach: DLX serves clients around the world, offering fast shipping and responsive customer support to ensure that your projects run smoothly and on schedule.
Commitment to Sustainability: As part of our mission to support the global shift to clean energy, DLX provides materials that contribute to the production of sustainable hydrogen, helping to reduce carbon emissions worldwide.

Frequently Asked Questions (FAQs)

What is 0Cr21Al6Nb FeCrAl Wire used for?
The 0Cr21Al6Nb FeCrAl Wire is used in electrolysis systems for hydrogen production, providing excellent oxidation and corrosion resistance in high-temperature electrolytic environments.
Can 0Cr21Al6Nb FeCrAl Wire handle extreme temperatures?
Yes, the wire can withstand temperatures up to 1000°C, making it ideal for high-temperature electrolysis systems.
How does 0Cr21Al6Nb FeCrAl Wire enhance electrolysis efficiency?
The wire's resistance to oxidation and corrosion helps maintain consistent performance and prevents degradation, ensuring that electrolysis systems operate efficiently over time.
Is customization available for this wire?
Yes, DLX offers customized wire diameters, tensile strengths, and other specifications to suit the unique needs of your electrolysis system.
How long does the 0Cr21Al6Nb FeCrAl Wire last?
Due to its excellent resistance to oxidation and corrosion, the 0Cr21Al6Nb FeCrAl Wire has a long service life, reducing the need for frequent replacements.
Is 0Cr21Al6Nb FeCrAl Wire cost-effective?
Yes, the wire's durability and long lifespan make it a cost-effective solution for large-scale hydrogen production systems, reducing maintenance and replacement costs.
What industries use 0Cr21Al6Nb FeCrAl Wire?
Industries such as hydrogen fuel cell technology, green hydrogen production, energy storage, and industrial hydrogen applications benefit from the 0Cr21Al6Nb FeCrAl Wire.
How does DLX support customers?
DLX offers expert guidance in selecting the best wire for your electrolysis system, along with customized solutions and excellent customer service to ensure your project's success.
